封装

Toshiba Package Name	TSOP6F
Package Image
Pins	6
Mounting	Surface Mount
Width×Length×Height (mm)	2.9×2.8×0.8
Package Dimensions	查看
Land pattern dimensions	查看
Ultra Librarian^® CAD model (Symbol, Footprint and 3D model)	Download from UltraLibrarian^® in your desired CAD format 1 3
SamacSys CAD model (Symbol, Footprint and 3D model)	Download from SamacSys 2 3

Please refer to the link destination to check the detailed size.

*1	Ultra Librarian^® is a Registered trademark and CAD model library of EMA (EMA Design Automation, Inc.). CAD models (Symbol/Footprint /3D model) are provided by UltraLibrarian^®. The footprints are generated based on the specifications of Ultra Librarian^®.
*2	SamacSys is a wholly owned subsidiary of Supplyframe, Inc. CAD models (Symbol/Footprint /3D model) are provided by Supplyframe, Inc. The footprints are generated based on the specifications of SamacSys.
*3	Please note that the footprint dimensions may differ from the reference Land Pattern dimensions provided on our website.

绝对最大额定值

项目	符号	值	单位
Drain-Source voltage	V_DSS	60	V
Gate-Source voltage	V_GSS	+/-20	V
Drain current	I_D	6.0	A
Power Dissipation	P_D	1.5	W

电气特性

项目	符号	条件	值	单位
Gate threshold voltage (Max)	V_th	-	2.5	V
Gate threshold voltage (Min)	V_th	-	1.5	V
Drain-Source on-resistance (Max)	R_DS(ON)	\|V_GS\|=4V	69	mΩ
Drain-Source on-resistance (Max)	R_DS(ON)	\|V_GS\|=4.5V	51	mΩ
Drain-Source on-resistance (Max)	R_DS(ON)	\|V_GS\|=10V	36	mΩ
Input capacitance (Typ.)	C_iss	-	550	pF
Total gate charge (Typ.)	Q_g	V_GS=10V	9.3	nC

文档

全部选中
如果该复选框不能被选中，则不能批量下载相应的文档。

数据表 SSM6K809R 数据表/日文

PDF: 512KB

Oct,2025

数据表 SSM6K809R 数据表/英文

PDF: 420KB

Oct,2025

Simulation Model PSpice Model lib

lib: 3KB

May,2020

Simulation Model LTspice Model * ZIP

ZIP: 11KB

Mar,2021

Thermal Simulation Model Simplified CFD Model ZIP

ZIP: 10KB

Feb,2024

Reliability Information Reliability Data

PDF: 246KB

Sep,2025

UPDATED Environment Information Certificate Regarding EU RoHS(2011/65/EU)Controlled Substances

PDF: 170KB

Apr,2026

UPDATED Environment Information Certificate on Content of SVHC of REACH

PDF: 162KB

Apr,2026

相关技术数据 Surface Mount Small Signal MOSFET Precautions for use

PDF: 830KB

Jan,2022

Catalog Selection Guide MOSFETs 2026 Rev1.0

PDF: 4223KB

Feb,2026

Catalog Selection Guide Small Signal 2026 Rev1.0

PDF: 8928KB

Jan,2026

Catalog Mini catalog Introduction of Semi-power & small-size low RON MOSFET

PDF: 323KB

Dec,2025

Catalog Mini catalog Introduction of small-package MOSFET

PDF: 476KB

Dec,2025

*	LTspice ^® is a trademark and simulation software of ADI (Analog Devices, Inc.).

Notes

The Part Number column shows representative part numbers only, which may not be available for sale in the precise form shown. Each Part Number constitutes a product family which may contain multiple associated product configurations.
(#) Under the RoHS Compatible Product(s) column, "Available" means at least one RoHS-Compatible product is available for sale in the corresponding product family. "None" means no RoHS Compatible product is available in that product family. For Toshiba's definitions of concepts related to the RoHS Directive and RoHS Compatibility, please click here.
The RoHS compatibility information provided herein is to the best of Toshiba's knowledge and belief accurate as of the date Toshiba entered the information into this database. Information is subject to change at any time without notice.
Please contact your Toshiba sales representative for detailed environmental information about each specific part number or product, such as RoHS compatibility or material content. Please use Toshiba products only in compliance with all applicable laws and regulations concerning the inclusion or use of controlled substances, including without limitation the RoHS Directive.TOSHIBA ASSUMES NO LIABILITY FOR DAMAGES OR LOSSES OCCURRING AS A RESULT OF NONCOMPLIANCE WITH APPLICABLE LAWS AND REGULATIONS.
Reliability data are provided for your reference only, please contact your Toshiba sales representative for detailed reliability information about each part number.
For product delivery, additional characters will be added to the part numbers shown on this website. For details, please ask your local distributor, or send an inquiry accessed from "Contact Us" on this website.

Application Scope	DC-DC Converters / Power Management Switches
Feature	Low drain-source on-resistance
Polarity	N-ch
Generation	U-MOSⅧ-H
Internal Connection	Single
PPAP	Capable(*)
AEC-Q101	Qualified(*)
RoHS Compatible Product(s) (#)	Available

Orderable part number (example)	MOQ(pcs)	Reliability Information	RoHS	AEC-Q100 AEC-Q101	Note
SSM6K809R,LF	3000		Yes	-	General Use
SSM6K809R,LXGF	3000	-	Yes	Yes (Note)	Unintended Use (Note)
SSM6K809R,LXHF	3000	-	Yes	Yes	Automotive Use
