无绳电动工具

总方框图

无绳电动工具

单击总方框图中想要查看详细信息的区域。将显示我们建议的子方框图的链接。

电机驱动电路

电机驱动电路直流无刷电机（采用驱动IC和外部MOSFET电路）

采用驱动IC和外部驱动MOSFET的无刷电机驱动电路示例

直流有刷电机／机械开关电机驱动电路

具有机械开关旋转切换功能的有刷电机驱动电路示例

直流有刷电机／MOSFET开关电机驱动电路

采用MOSFET的H桥带旋转开关功能的有刷电机驱动电路示例

MCU外围电路

使用运算放大器和LDO的微控制器电源和信号输入等外围电路示例

电池充电电路

用于电池充电的AC-DC电源电路示例

子方框图

电机驱动电路

电机驱动电路直流无刷电机（采用驱动IC和外部MOSFET电路）

采用驱动IC和外部驱动MOSFET的无刷电机驱动电路示例

Gate driver (1)
Gate driver (2)
U-MOS Series MOSFET (1)
U-MOS Series MOSFET (2)

Integrate functions required as a gate driver for driving motors of power tools into single IC

器件型号	TB67Z833SFTG	TB67Z833HFTG	TB67Z830SFTG	TB67Z830HFTG
Toshiba Package Name	P-WQFN40-0606-0.50-003	P-WQFN40-0606-0.50-003	P-VQFN32-0505-0.50-007	P-VQFN32-0505-0.50-007
V_OUT (Max) [V]	80	80	80	80
I_OUT (Max) [A]	2	2	2	2
V_M [V]	8 to 75	8 to 75	8 to 75	8 to 75
R_ON (Typ.) [Ω]

搜索产品线

Integrate functions required as a gate driver for driving motors of power tools into single IC

器件型号	TB67Z853SFTG	TB67Z853HFTG	TB67Z850SFTG	TB67Z850HFTG
Toshiba Package Name	P-WQFN40-0606-0.50-003	P-WQFN40-0606-0.50-003	P-VQFN32-0505-0.50-007	P-VQFN32-0505-0.50-007
V_OUT (Max) [V]	80	80	80	80
I_OUT (Max) [A]	2	2	2	2
V_M [V]	8 to 75	8 to 75	8 to 75	8 to 75
R_ON (Typ.) [Ω]

搜索产品线

MOSFET with low on-resistance and high heat dissipation efficiency

器件型号	TPWR6003PL	TPWR8004PL	TPHR8504PL	TPHR7404PU
Toshiba Package Name	DSOP Advance	DSOP Advance	SOP Advance	SOP Advance
V_DSS (Max) [V]	30	40	40	40
I_D (Max) [A]	412	340	340	400
R_DS(ON) (Max) [Ω] @ \|V_GS\| = 10.0 [V]	0.0006	0.0008	0.00085	0.00074
Polarity	N-ch	N-ch	N-ch	N-ch

搜索产品线

MOSFET with low on-resistance and high heat dissipation efficiency

器件型号	TPH2R408QM	TPH4R008QM	TK5R1P08QM	TK6R9P08QM
Toshiba Package Name	SOP Advance	SOP Advance(N)	DPAK	DPAK
V_DSS (Max) [V]	80	80	80	80
I_D (Max) [A]	120	86	84	62
R_DS(ON) (Max) [Ω] @ \|V_GS\| = 10.0 [V]	0.00243	0.004	0.0051	0.0069
Polarity	N-ch	N-ch	N-ch	N-ch

搜索产品线

直流有刷电机／机械开关电机驱动电路

具有机械开关旋转切换功能的有刷电机驱动电路示例

Bipolar transistor
U-MOS Series MOSFET (1)
U-MOS Series MOSFET (2)

Bipolar transistor for gate driving

器件型号	TMBT3906	TMBT3904	2SC4116
Toshiba Package Name	SOT-23 (SOT23)	SOT-23 (SOT23)	SOT-323 (USM)
V_CEO (Max) [V]	-50	50	50
I_C (Max) [A]	-0.2	0.2	0.15
Polarity	PNP	NPN	NPN

搜索产品线

MOSFET with low on-resistance and high heat dissipation efficiency

器件型号	TPWR6003PL	TPWR8004PL	TPHR8504PL	TPHR7404PU
Toshiba Package Name	DSOP Advance	DSOP Advance	SOP Advance	SOP Advance
V_DSS (Max) [V]	30	40	40	40
I_D (Max) [A]	412	340	340	400
R_DS(ON) (Max) [Ω] @ \|V_GS\| = 10.0 [V]	0.0006	0.0008	0.00085	0.00074
Polarity	N-ch	N-ch	N-ch	N-ch

搜索产品线

MOSFET with low on-resistance and high heat dissipation efficiency

器件型号	TPH2R408QM	TPH4R008QM	TK5R1P08QM	TK6R9P08QM
Toshiba Package Name	SOP Advance	SOP Advance(N)	DPAK	DPAK
V_DSS (Max) [V]	80	80	80	80
I_D (Max) [A]	120	86	84	62
R_DS(ON) (Max) [Ω] @ \|V_GS\| = 10.0 [V]	0.00243	0.004	0.0051	0.0069
Polarity	N-ch	N-ch	N-ch	N-ch

搜索产品线

直流有刷电机／MOSFET开关电机驱动电路

采用MOSFET的H桥带旋转开关功能的有刷电机驱动电路示例

U-MOS Series MOSFET (1)
U-MOS Series MOSFET (2)

MOSFET with low on-resistance and high heat dissipation efficiency

器件型号	TPWR6003PL	TPWR8004PL	TPHR8504PL	TPHR7404PU
Toshiba Package Name	DSOP Advance	DSOP Advance	SOP Advance	SOP Advance
V_DSS (Max) [V]	30	40	40	40
I_D (Max) [A]	412	340	340	400
R_DS(ON) (Max) [Ω] @ \|V_GS\| = 10.0 [V]	0.0006	0.0008	0.00085	0.00074
Polarity	N-ch	N-ch	N-ch	N-ch

搜索产品线

MOSFET with low on-resistance and high heat dissipation efficiency

器件型号	TPH2R408QM	TPH4R008QM	TK5R1P08QM	TK6R9P08QM
Toshiba Package Name	SOP Advance	SOP Advance(N)	DPAK	DPAK
V_DSS (Max) [V]	80	80	80	80
I_D (Max) [A]	120	86	84	62
R_DS(ON) (Max) [Ω] @ \|V_GS\| = 10.0 [V]	0.00243	0.004	0.0051	0.0069
Polarity	N-ch	N-ch	N-ch	N-ch

搜索产品线

MCU外围电路

使用运算放大器和LDO的微控制器电源和信号输入等外围电路示例

Low noise operational amplifier
Small surface mount LDO regulator
MCU

Amplifies signals detected by various sensors with low noise

器件型号	TC75S67TU
Toshiba Package Name	SOT-353F (UFV)
V_CC (Max) [V]	5.5
V_CC, V_EE (Max) [V]	+/-2.75

搜索产品线

Small surface mount LDO regulator suitable for power tools having high noise

器件型号	TCR1HF Series
Toshiba Package Name	SOT-25 (SMV)
I_OUT (Max) [mA]	150
V_OUT [V]	1.8 to 5.0

搜索产品线

MCU suitable for motor control

Series	TXZ+^TM 4A Series	TX04 Series	TX03 Series
Group	M4K Group	M470 Group	M370 Group

搜索产品线

电池充电电路

用于电池充电的AC-DC电源电路示例

Suitable for high efficiency power switching

器件型号	TK12A60W	TK10A60W	TK17A80W
Toshiba Package Name	TO-220SIS	TO-220SIS	TO-220SIS
V_DSS (Max) [V]	600	600	800
I_D (Max) [A]	11.5	9.7	17
R_DS(ON) (Max) [Ω] @ \|V_GS\| = 10.0 [V]	0.3	0.38	0.29
Polarity	N-ch	N-ch	N-ch

搜索产品线

Bipolar transistor for gate driving

器件型号	TMBT3906	TMBT3904	2SC4116
Toshiba Package Name	SOT-23 (SOT23)	SOT-23 (SOT23)	SOT-323 (USM)
V_CEO (Max) [V]	-50	50	50
I_C (Max) [A]	-0.2	0.2	0.15
Polarity	PNP	NPN	NPN

搜索产品线

Small signal MOSFET for low voltage switching

器件型号	SSM6K513NU	SSM6N55NU	SSM6J507NU
Toshiba Package Name	SOT-1220 (UDFN6B)	SOT-1118 (UDFN6)	SOT-1220 (UDFN6B)
V_DSS (Max) [V]	30	30	-30
I_D (Max) [A]	15	4	-10
R_DS(ON) (Max) [Ω] @ \|V_GS\| = 4.5 [V]	0.012	0.064	0.028
Polarity	N-ch	N-ch×2	P-ch

搜索产品线

High current transfer ratio and high temperature operation

器件型号	TLP383
Toshiba Package Name	4pin SO6L
BV_S (Min) [V_rms] @ t = 60 [s]	5000
V_CEO (Max) [V]	80
T_opr [°C]	-55 to 125

搜索产品线

Low noise operational amplifier to capture fluctuations in current consumption accurately

器件型号	TC75S67TU
Toshiba Package Name	SOT-353F (UFV)
V_CC (Max) [V]	5.5
V_CC, V_EE (Max) [V]	+/-2.75

搜索产品线

eFuse IC for robust protection

器件型号	TCKE800NA	TCKE800NL	TCKE805NA	TCKE805NL	TCKE812NA	TCKE812NL
Toshiba Package Name	WSON10B	WSON10B	WSON10B	WSON10B	WSON10B	WSON10B
V_IN (Max) [V]	18	18	18	18	18	18
R_ON (Typ.) [mΩ]	28	28	28	28	28	28
V_OVC (Typ.) [V]			6.04	6.04	15.1	15.1
Recovery Operation Type	Auto-retry	Latch	Auto-retry	Latch	Auto-retry	Latch

搜索产品线

eFuse IC for robust protection

器件型号	TCKE712BNL	TCKE903NA	TCKE903NL	TCKE903QNA	TCKE905ANA	TCKE905NL
Toshiba Package Name	WSON10	WSON8	WSON8	WSON8	WSON8	WSON8
V_IN (Max) [V]	13.2	23	23	23	23	23
R_ON (Typ.) [mΩ]	53	34	34	34	34	34
V_OVC (Typ.) [V]		3.87	3.87		5.7	5.7
Recovery Operation Type	Latch	Auto-retry	Latch	Auto-retry	Auto-retry	Latch

搜索产品线

eFuse IC for robust protection

器件型号	TCKE905QNA	TCKE912NA	TCKE912NL	TCKE920NA	TCKE920NL
Toshiba Package Name	WSON8	WSON8	WSON8	WSON8	WSON8
V_IN (Max) [V]	23	23	23	23	23
R_ON (Typ.) [mΩ]	34	34	34	34	34
V_OVC (Typ.) [V]		13.7	13.7	22.2	22.2
Recovery Operation Type	Auto-retry	Auto-retry	Latch	Auto-retry	Latch
