监控摄像头

总方框图

监控摄像头

单击总方框图中想要查看详细信息的区域。将显示我们建议的子方框图的链接。

电源

为系统提供各种直流电压的电源电路示例

存储电源电路

存储电源电路示例

SD卡部分

SD卡的电源电路示例

电源（RTC）

考虑防止实时时钟（RTC）电池反向连接的电源电路示例

相机运动部分详情

摄像头运动单元详情

摄像头运动单元的电路示例

子方框图

电源

为系统提供各种直流电压的电源电路示例

U-MOS Series N-ch MOSFET
Small signal MOSFET
Small surface mount LDO regulator(1)
Small surface mount LDO regulator(2)

U-MOS Series N-ch MOSFET

器件型号	TPH5900CNH
Toshiba Package Name	SOP Advance
V_DSS (Max) [V]	150
I_D (Max) [A]	18
R_DS(ON) (Max) [Ω] @ \|V_GS\| = 10.0 [V]	0.059
Polarity	N-ch

搜索产品线

Small signal MOSFET

器件型号	SSM3K376R
Toshiba Package Name	SOT-23F
V_DSS (Max) [V]	30
I_D (Max) [A]	4
R_DS(ON) (Max) [Ω] @ \|V_GS\| = 4.5 [V]	0.056
Polarity	N-ch

搜索产品线

Small surface mount LDO regulator(1)

器件型号	TCR15AG Series	TCR13AG Series	TCR8BM Series	TCR5BM Series
Toshiba Package Name	WCSP6F	WCSP6F	DFN5B	DFN5B
I_OUT (Max) [mA]	1500	1300	800	500
V_OUT [V]	0.6 to 3.6	0.55 to 3.6	0.8 to 3.6	0.8 to 3.6

搜索产品线

Small surface mount LDO regulator(2)

器件型号	TCR5RG Series	TCR3RM Series	TCR3U Series	TCR2L Series	TAR5 Series
Toshiba Package Name	WCSP4F	DFN4F	WCSP4F	SOT-553 (ESV)	SOT-25 (SMV)
I_OUT (Max) [mA]	500	300	300	200	200
V_OUT [V]	0.9 to 5.0	0.9 to 4.5	0.8 to 5.0	0.8 to 3.6	1.5 to 5.0

搜索产品线

存储电源电路

存储电源电路示例

Electronic fuse (eFuse IC)(1)
Electronic fuse (eFuse IC)(2)
N-ch MOSFET gate driver IC(1)
N-ch MOSFET gate driver IC(2)

Electronic fuse (eFuse IC)(1)

器件型号	TCKE800NA	TCKE805NA	TCKE812NA
Toshiba Package Name	WSON10B	WSON10B	WSON10B
V_IN (Max) [V]	18	18	18
R_ON (Typ.) [mΩ]	28	28	28
V_OVC (Typ.) [V]		6.04	15.1
Recovery Operation Type	Auto-retry	Auto-retry	Auto-retry

搜索产品线

Electronic fuse (eFuse IC)(2)

器件型号	TCKE800NL	TCKE805NL	TCKE812NL	TCKE712BNL
Toshiba Package Name	WSON10B	WSON10B	WSON10B	WSON10
V_IN (Max) [V]	18	18	18	13.2
R_ON (Typ.) [mΩ]	28	28	28	53
V_OVC (Typ.) [V]		6.04	15.1
Recovery Operation Type	Latch	Latch	Latch	Latch

搜索产品线

N-ch MOSFET gate driver IC(1)

器件型号	TCK401G	TCK402G	TCK420G	TCK421G	TCK422G
Toshiba Package Name	WCSP6E	WCSP6E	WCSP6G	WCSP6G	WCSP6G
V_{OVL_FA} (Typ.) [V]			27.56	23.14	14.17
V_{OVL_RI} (Typ.) [V]			27.73	23.26	14.29
V_GS (Typ.) [V]	8.5	8.5	10	10	10

搜索产品线

N-ch MOSFET gate driver IC(2)

器件型号	TCK423G	TCK424G	TCK425G
Toshiba Package Name	WCSP6G	WCSP6G	WCSP6G
V_{OVL_FA} (Typ.) [V]	14.17	10.71	6.19
V_{OVL_RI} (Typ.) [V]	14.29	10.83	6.31
V_GS (Typ.) [V]	5.6	5.6	5.6

搜索产品线

SD卡部分

SD卡的电源电路示例

Small surface mount LDO regulator(1)
Small surface mount LDO regulator(2)
TVS diode

Small surface mount LDO regulator(1)

器件型号	TCR15AG Series	TCR13AG Series	TCR8BM Series	TCR5BM Series
Toshiba Package Name	WCSP6F	WCSP6F	DFN5B	DFN5B
I_OUT (Max) [mA]	1500	1300	800	500
V_OUT [V]	0.6 to 3.6	0.55 to 3.6	0.8 to 3.6	0.8 to 3.6

搜索产品线

Small surface mount LDO regulator(2)

器件型号	TCR5RG Series	TCR3RM Series	TCR3U Series	TCR2L Series	TAR5 Series
Toshiba Package Name	WCSP4F	DFN4F	WCSP4F	SOT-553 (ESV)	SOT-25 (SMV)
I_OUT (Max) [mA]	500	300	300	200	200
V_OUT [V]	0.9 to 5.0	0.9 to 4.5	0.8 to 5.0	0.8 to 3.6	1.5 to 5.0

搜索产品线

TVS diode

器件型号	DF10G5M4N	DF10G6M4N	DF2B5M4ASL	DF2B6M4ASL	DF2B6M4BSL
Toshiba Package Name	DFN10	DFN10	SOD-962 (SL2)	SOD-962 (SL2)	SOD-962 (SL2)
V_ESD (Max) [kV]	+/-20	+/-20	+/-16	+/-15	+/-8
I_R (Max) [µA]	0.1	0.1	0.1	0.1	0.1
R_dyn (Typ.) [Ω]	0.5	0.5	0.7	0.7	1.05
C_T (Typ.) [pF] @ V_R = 0 [V], f = 1 [MHz]	0.2	0.2	0.15	0.15	0.12

搜索产品线

电源（RTC）

考虑防止实时时钟（RTC）电池反向连接的电源电路示例

Schottky barrier diode

Schottky barrier diode

器件型号	CUS10F30	CTS05F40
Toshiba Package Name	SOD-323 (USC)	SOD-882 (CST2)
V_RRM (Max) [V]
V_R (Max) [V]	30	40
C_T (Typ.) [pF]	170	28

搜索产品线

相机运动部分详情

摄像头运动单元详情

摄像头运动单元的电路示例

Stepping motor
Brushed DC motor driver
Stepping motor driver

Stepping motor

器件型号	TC78S121FNG	TC78S121FTG	TC78S122FNG	TC78S122FTG	TC78H670FTG
Toshiba Package Name	HTSSOP48-P-300-0.50	QFN48-P-0707-0.50	HTSSOP48-P-300-0.50	QFN48-P-0707-0.50	P-VQFN16-0303-0.50-001
V_OUT (Max) [V]	40	40	40	40	18
I_OUT (Max) [A]	1.5	1.5	1.5	1.5	2
V_M [V]	8 to 38	8 to 38	8 to 38	8 to 38	2.5 to 16
R_ON (Typ.) [Ω]	0.6	0.6	0.6	0.6	0.48

搜索产品线

Brushed DC motor driver

器件型号	TC78H660FNG	TC78H660FTG	TC78H653FTG
Toshiba Package Name	P-TSSOP16-0505-0.65-001	P-VQFN16-0303-0.50-001	P-VQFN16-0303-0.50-001
V_OUT (Max) [V]	18	18	8
I_OUT (Max) [A]	2	2	2
V_M [V]	2.5 to 16	2.5 to 16	1.8 to 7.5
R_ON(Normal) (Typ.) [Ω]	0.48	0.48	0.22
R_ON(Large) (Typ.) [Ω]			0.11
