TLP385

Feature	2.3mm low-profile package / DC input
Application Scope	Communication interface / PLC / Power supply
Function	General-purpose
Number of Circuits	1
Input type	DC
RoHS Compatible Product(s) (#)	Available
Safety Standard	Approved　:　UL 1577 / cUL (CSA Component Acceptance Service No. 5A) / EN 60747-5-5 (VDE) / EN IEC 62368-1 (VDE) / GB 4943.1-2022 (CQC) Download Online Certification of Safety Standard(UL 1577) Download Online Certification of Safety Standard(cUL)

封装

Toshiba Package Name	4pin SO6L
Package Image
Pins	4
Mounting	Surface Mount
Width×Length×Height (mm)	3.84×10.0×2.1
Package Dimensions	查看
Land pattern dimensions	查看
CAD data (Symbol, Footprint and 3D model)	Download from UltraLibrarian^® in your desired CAD format (Note)

Please refer to the link destination to check the detailed size.

(Note) Ultra Librarian^® is a Registered trademark and CAD data library of EMA (EMA Design Automation, Inc.).

绝对最大额定值

项目	符号	值	单位
Collector-emitter voltage	V_CEO	80	V
Collector Current	I_C	0.05	A
Forward Current	I_F	0.05	A
Operating Temperature	T_opr	-55 to 110	℃

电气特性

项目	符号	条件	值	单位
Collector Emitter Saturation Voltage (Max)	V_CE(sat)	-	0.3	V
Isolation voltage BVs @1minute (Min)	BV_S	t=60sec	5000	Vrms
Current Transfer Ratio (Max)	CTR	I_F=5mA V_CE=5V rank=-	600	%
Current Transfer Ratio (Min)	CTR	I_F=5mA V_CE=5V rank=-	50	%

文档

全部选中
如果该复选框不能被选中，则不能批量下载相应的文档。

数据表 TLP385 数据表/日文

PDF: 952KB

May,2022

数据表 TLP385 数据表/英文

PDF: 796KB

May,2022

Simulation Model PSpice Model ZIP

ZIP: 4KB

Jul,2018

Reliability Information Reliability Data

PDF: 200KB

Dec,2023

相关技术数据 Safety standards for photocouplers

PDF: 753KB

Mar,2021

相关技术数据 Glossary of Photocoupler and Photorelay Terms

PDF: 509KB

Mar,2018

Catalog Selection Guide Isolators and Solid State Relays 2024Rev1.0

PDF: 8070KB

Feb,2024

Catalog Photocouplers and Photorelays

PDF: 2619KB

Apr,2020

Catalog Photocouplers and Photorelays Product Notes

PDF: 6083KB

Sep,2017

可订购器件型号

Orderable part number (example)	MOQ(pcs)	RoHS	Current Transfer Ratio (%)	VDE
TLP385(BL-TPL,E	3000	Yes	BL (200%-600%)	-
TLP385(BLL-TPL,E	3000	Yes	BLL(200%-400%)	-
TLP385(D4-GRH,E	125	Yes	GRH(150-300%)	Yes
TLP385(D4-GRL,E	125	Yes	GRL(100-200%)	Yes
TLP385(D4-TPL,E	3000	Yes	-	Yes
TLP385(D4BL-TL,E	3000	Yes	BL (200%-600%)	Yes
TLP385(D4BLLTL,E	3000	Yes	BLL(200%-400%)	Yes
TLP385(D4GB-TL,E	3000	Yes	GB(100%-600%)	Yes
TLP385(D4GH-TL,E	3000	Yes	GRH(150%-300%)	Yes
TLP385(D4GL-TL,E	3000	Yes	GRL(100%-200%)	Yes
TLP385(D4GR-TL,E	3000	Yes	GR(100%-300%)	Yes
TLP385(D4Y-TPL,E	3000	Yes	Y(50%-150%)	Yes
TLP385(D4YH-TL,E	3000	Yes	YH(75%-150%)	Yes
TLP385(GB-TPL,E	3000	Yes	GB(100%-600%)	-
TLP385(GR-TPL,E	3000	Yes	GR(100%-300%)	-
TLP385(GRH-TPL,E	3000	Yes	GRH(150%-300%)	-
TLP385(GRL-TPL,E	3000	Yes	GRL(100%-200%)	-
TLP385(TPL,E	3000	Yes	-	-
TLP385(Y-TPL,E	3000	Yes	Y(50%-150%)	-
TLP385(YH-TPL,E	3000	Yes	YH(75%-150%)	-

应用

空气净化器

Such as high efficiency, low power consumption and miniaturization are important in designing air cleaner. Toshiba provides information on a wide range of semiconductor products suitable for power supply unit, motor driving units, sensor signal input unit, etc., along with circuit configuration examples.

详细信息

喷墨打印机

Such as efficiency of motor driving, low power consumption and miniaturization are important in designing inkjet printer. Toshiba provides information on a wide range of semiconductor products suitable for power supply unit, engine (motor driving) units, scanner unit, etc., along with circuit configuration examples.

详细信息

Multi Function Printer

Such as efficiency of motor driving, low power consumption and miniaturization are important in designing multi function printer (MFP). Toshiba provides information on a wide range of semiconductor products suitable for power sullpy units, engine (motor driving) units, scanner units, control units, etc., along with circuit configuration examples.

详细信息

Thermostat

Such as low power consumption and miniaturization are important in designing thermostat. Toshiba provides information on a wide range of semiconductor products suitable for power supply units, isolation units, sensor signal input units, etc., along with circuit configuration examples.

详细信息

LED照明

Such as high efficiency, low power consumption and miniaturization are important in designing LED lighting. Toshiba provides information on a wide range of semiconductor products suitable for power supply units, sensor signal input units, etc., along with circuit configuration examples.

详细信息

微波炉

Such as low noise, low power consumption and miniaturization are important in designing microwave oven. Toshiba provides information on a wide range of semiconductor products suitable for power supply unit, magnetron driving circuit units, sensor signal input units, etc., along with circuit configuration examples.

详细信息

Cordless Power Tool

Such as low power consumption and miniaturization are important in designing cordless power tools. Toshiba provides information on a wide range of semiconductor products suitable for motor drive units, control units, power supply and charge management units, etc., along with circuit configuration examples.

详细信息

变频器／伺服

Such as low power consumption, miniaturization and robust operation are important in designing inverter/servo. Toshiba provides information on a wide range of semiconductor products suitable for power supply unit, motor driving circuit units, signal transmission units, etc., along with circuit configuration examples.

详细信息

空调

Such as efficiency of motor driving, low power consumption and miniaturization are important in designing air conditioner. Toshiba provides information on a wide range of semiconductor products suitable for power sullpy units, motor driving units, control units, sensor signal input units, etc., along with circuit configuration examples.

详细信息

洗衣机

Such as efficiency of motor driving, low power consumption and miniaturization are important in designing washing machine. Toshiba provides information on a wide range of semiconductor products suitable for power sullpy units, motor driving units, control units, sensor signal input units, etc., along with circuit configuration examples.

详细信息

Notes

The Part Number column shows representative part numbers only, which may not be available for sale in the precise form shown. Each Part Number constitutes a product family which may contain multiple associated product configurations.
(#) Under the RoHS Compatible Product(s) column, "Available" means at least one RoHS-Compatible product is available for sale in the corresponding product family. "None" means no RoHS Compatible product is available in that product family. For Toshiba's definitions of concepts related to the RoHS Directive and RoHS Compatibility, please click here.
The RoHS compatibility information provided herein is to the best of Toshiba's knowledge and belief accurate as of the date Toshiba entered the information into this database. Information is subject to change at any time without notice.
Please contact your Toshiba sales representative for detailed environmental information about each specific part number or product, such as RoHS compatibility or material content. Please use Toshiba products only in compliance with all applicable laws and regulations concerning the inclusion or use of controlled substances, including without limitation the RoHS Directive.TOSHIBA ASSUMES NO LIABILITY FOR DAMAGES OR LOSSES OCCURRING AS A RESULT OF NONCOMPLIANCE WITH APPLICABLE LAWS AND REGULATIONS.
Reliability data are provided for your reference only, please contact your Toshiba sales representative for detailed reliability information about each part number.
For product delivery, additional characters will be added to the part numbers shown on this website. For details, please ask your local distributor, or send an inquiry accessed from "Contact Us" on this website.
