封装

Toshiba Package Name	4pin SO6
Package Image
Pins	4
Mounting	Surface Mount
Width×Length×Height (mm)	3.7×7.0×2.1
Package Dimensions	查看
Land pattern dimensions	查看
Ultra Librarian^® CAD model (Symbol, Footprint and 3D model)	Download from UltraLibrarian^® in your desired CAD format (Note1)(Note3)
SamacSys CAD model (Symbol, Footprint and 3D model)	Download from SamacSys (Note2)(Note3)

Please refer to the link destination to check the detailed size.

(Note1)	Ultra Librarian^® is a Registered trademark and CAD model library of EMA (EMA Design Automation, Inc.). CAD models (Symbol/Footprint /3D model) are provided by UltraLibrarian^®. The footprints are generated based on the specifications of Ultra Librarian^®.
(Note2)	SamacSys is a wholly owned subsidiary of Supplyframe, Inc. CAD models (Symbol/Footprint /3D model) are provided by Supplyframe, Inc. The footprints are generated based on the specifications of SamacSys.
(Note3)	Please note that the footprint dimensions may differ from the reference Land Pattern dimensions provided on our website.

绝对最大额定值

项目	符号	值	单位
Collector-emitter voltage	V_CEO	80	V
Collector Current	I_C	0.05	A
Forward Current	I_F	0.05	A
Operating Temperature	T_opr	-55 to 110	℃

电气特性

项目	符号	条件	值	单位
Collector Emitter Saturation Voltage (Max)	V_CE(sat)	-	0.3	V
Isolation voltage BVs @1minute (Min)	BV_S	t=60sec	3750	Vrms
Current Transfer Ratio (Max)	CTR	I_F=5mA V_CE=5V rank=-	600	%
Current Transfer Ratio (Min)	CTR	I_F=5mA V_CE=5V rank=-	50	%

文档

全部选中
如果该复选框不能被选中，则不能批量下载相应的文档。

数据表 TLP185(SE 数据表/日文

PDF: 440KB

Nov,2019

数据表 TLP185(SE 数据表/英文

PDF: 291KB

Nov,2019

Simulation Model PSpice Model ZIP

ZIP: 4KB

Oct,2018

Simulation Model LTspice Model (Note) ZIP

ZIP: 7KB

Feb,2019

UPDATED Reliability Information Reliability Data

PDF: 173KB

Oct,2025

UPDATED Environment Information Certificate Regarding EU RoHS(2011/65/EU)Controlled Substances

PDF: 86KB

Oct,2025

UPDATED Environment Information Certificate on Content of SVHC of REACH

PDF: 85KB

Oct,2025

相关技术数据 Application note for phototransistor coupler

PDF: 8247KB

Jul,2025

相关技术数据 Safety standards for photocouplers

PDF: 753KB

Mar,2021

相关技术数据 Glossary of Photocoupler and Photorelay Terms

PDF: 509KB

Mar,2018

Catalog Selection Guide Isolators and Solid State Relays 2025Rev1.0

PDF: 7871KB

Feb,2025

Catalog Photocouplers and Photorelays

PDF: 2619KB

Apr,2020

(Note)

LTspice ^® is a trademark and simulation software of ADI (Analog Devices, Inc.).

Notes

The Part Number column shows representative part numbers only, which may not be available for sale in the precise form shown. Each Part Number constitutes a product family which may contain multiple associated product configurations.
(#) Under the RoHS Compatible Product(s) column, "Available" means at least one RoHS-Compatible product is available for sale in the corresponding product family. "None" means no RoHS Compatible product is available in that product family. For Toshiba's definitions of concepts related to the RoHS Directive and RoHS Compatibility, please click here.
The RoHS compatibility information provided herein is to the best of Toshiba's knowledge and belief accurate as of the date Toshiba entered the information into this database. Information is subject to change at any time without notice.
Please contact your Toshiba sales representative for detailed environmental information about each specific part number or product, such as RoHS compatibility or material content. Please use Toshiba products only in compliance with all applicable laws and regulations concerning the inclusion or use of controlled substances, including without limitation the RoHS Directive.TOSHIBA ASSUMES NO LIABILITY FOR DAMAGES OR LOSSES OCCURRING AS A RESULT OF NONCOMPLIANCE WITH APPLICABLE LAWS AND REGULATIONS.
Reliability data are provided for your reference only, please contact your Toshiba sales representative for detailed reliability information about each part number.
For product delivery, additional characters will be added to the part numbers shown on this website. For details, please ask your local distributor, or send an inquiry accessed from "Contact Us" on this website.

Feature	2.3mm low-profile package / DC input
Application Scope	Communication interface / PLC / Power supply
Function	General-purpose
Number of Circuits	1
Input type	DC
RoHS Compatible Product(s) (#)	Available
Safety Standard	Approved　:　UL 1577 / cUL (CSA Component Acceptance Service No. 5A) / EN 60747-5-5 (VDE) / EN IEC 62368-1 (VDE) / GB 4943.1-2022 (CQC) Download Online Certification of Safety Standard(UL 1577) Download Online Certification of Safety Standard(cUL)

Orderable part number (example)	MOQ(pcs)	RoHS	Current Transfer Ratio (%)	VDE
TLP185(BL-TPL,SE	3000	Yes	BL (200%-600%)	-
TLP185(BLL-TL,SE	3000	Yes	BLL(200%-400%)	-
TLP185(GB-TPL,SE	3000	Yes	GB(100%-600%)	-
TLP185(GR-TPL,SE	3000	Yes	GR(100%-300%)	-
TLP185(GRH-TL,SE	3000	Yes	GRH(150%-300%)	-
TLP185(GRL-TL,SE	3000	Yes	GRL(100%-200%)	-
TLP185(TPL,SE	3000	Yes	-	-
TLP185(V4-TPL,SE	3000	Yes	-	Yes
TLP185(V4B-TL,SE	3000	Yes	BLL(200%-400%)	Yes
TLP185(V4BLTL,SE	3000	Yes	BL (200%-600%)	Yes
TLP185(V4GBTL,SE	3000	Yes	GB(100%-600%)	Yes
TLP185(V4GHTL,SE	3000	Yes	GRH(150%-300%)	Yes
TLP185(V4GLTL,SE	3000	Yes	GRL(100%-200%)	Yes
TLP185(V4GRTL,SE	3000	Yes	GR(100%-300%)	Yes
TLP185(V4Y-TL,SE	3000	Yes	Y(50%-150%)	Yes
TLP185(V4YHTL,SE	3000	Yes	YH(75%-150%)	Yes
TLP185(Y-TPL,SE	3000	Yes	Y(50%-150%)	-
TLP185(YH-TPL,SE	3000	Yes	YH(75%-150%)	-
