MOSFET4引脚封装TO-247-4L（TK25Z60X）应用电路

该参考设计提供了使用4引线MOSFET封装（TO-247-4L）最大限度提高开关性能和效率的示例电路，该封装可降低封装电感。

器件和PCB印制线的寄生电感
仿真电路

特点

  • Introduction of TO-247-4L package with 4-lead structure including additional source terminal
  • Achieves reduced gate signal oscillation and lower switching loss than 3-lead package
  • Minimizes impact of parasitic inductance in source wiring

Design Documents

Materials for designers, such as an overview of circuit operation and explanations of design considerations. Please click on each tab to view the contents.

Design Data

Provides circuit data that can be loaded into EDA tools, PCB layout data, and data used in PCB manufacturing. Available in formats from multiple tool vendors. You can freely edit it with your preferred tool.

东芝产品

器件型号 器件目录 搭载部位・数量 说明
功率MOSFET（N沟道500V＜VDSS≤700V） N沟道MOSFET，600V，0.125Ω@10V，TO-247-4L，DTMOSⅣ-H

Related Documents

We provide materials useful for designing and considering similar circuits, such as application notes for installed products. Please click on each tab to view the contents.
