IGBT／IEGT
点击产品目录，您可以查看IGBT／IEGT器件命名规则。
分立IGBT
1. 分立IGBT
2. 集电极额定电流（DC）
3. 额定电压（参见表1）
4.
- 1: N沟道
- 2: P沟道
- 3: 内置续流二极管的N沟道
- R: 内置续流二极管的N沟道RC-IGBT
5. 序列号
6. 版本
| 字母 | 电压 （V） |
字母 | 电压 （V） |
字母 | 电压 （V） |
|---|---|---|---|---|---|
| C | 150 | J | 600 | Q | 1200 |
| D | 200 | K | 700 | R | 1300 |
| E | 250 | L | 800 | S | 1400 |
| F | 300 | M | 900 | T | 1500 |
| G | 400 | N | 1000 | U | 1600 |
| H | 500 | P | 1100 | V | 1700 |
IEGT
1. 压接式IEGT（PPI）
2. 集电极额定电流
例）2100：2100A
3. 额定电压
| 字母 | 电压（V) |
|---|---|
| V | 1700 |
| FXF | 3300 |
| GXH | 4500 |
4. 序列号
5.
- A：仅晶体管
- 无后缀：内置续流二极管的晶体管
1. 塑料外壳模块IEGT（PMI）
2. 集电极额定电流
例）1200：1200A
3. 额定电压
| 字母 | 电压（V) |
|---|---|
| V | 1700 |
| FXF | 3300 |
| GXH | 4500 |
4. 元件数
例） 1：单个
5. 电路配置
6. 芯片类型
- S：N沟道
7. 序列号
