GT20N135SRA

新产品

IGBT for soft switching applications

产品概要

Feature High rugged / Low saturation voltage
Number of Circuits 2
Built-in Diodes Yes
RoHS Compatible Product(s) (#) Available

封装

Toshiba Package Name TO-247
Package Image TO-247
Pins 3
Mounting Through Hole
Width×Length×Height
(mm)
15.94×20.95×5.02
Package Dimensions 查看

 Please refer to the link destination to check the detailed size.

绝对最大额定值

项目 符号 单位
Collector Current IC 40 A
Collector-emitter voltage VCES 1350 V
购买及样品申请
请联系东芝官方代理商或就近联系我们的销售网点。
您可以通过以下链接搜索及购买少量样品。

文档

  • 如果该复选框不能被选中,则不能批量下载相应的文档。
名称 日期

Oct,2021

Oct,2021



  • 如果该复选框不能被选中,则不能批量下载相应的文档。

可订购器件型号

Orderable part number
(example)
MOQ(pcs) Reliability
Information
RoHS
GT20N135SRA,S1E(S 30 - Yes
