CMOS逻辑IC

从耐压18V的标准系列到具有1.2V运行保证的VCX系列，东芝提供丰富的CMOS逻辑IC产品线。东芝CMOS逻辑IC适用于工业设备到移动设备的各种应用。VHC／LCX／VCX系列具有全面的接口功能（输入容限、掉电保护等），支持不同电源电压IC之间连接，通过关闭不使用的电路块（局部掉电），从而实现设备节能

产品线

You can narrow down the search for applicable products by selecting specifications.

Function1
Function2
Number of Circuits
VCC (Max) (V)
Package name (Toshiba)
AEC-Q100
